RAID Enclosure QNAP (TR-004, Without HDD.)

TR-004

• Micro processor with hardware RAID

NONE

NONE

NONE

• 4 Drive Bay

• SATA 6Gb/s, 3Gb/s hard disk drives

• 1 x Type-C USB 3.2 Gen 1 (USB 3.2 Gen 1)

NONE

NONE

• monitoring with LED

• RAID 0/1/5/10

• QNAP NAS: QTS 4.3.6 and later
• Windows: Windows 8.1 and later
• Mac: macOS X 10.11 and later

• QNAP External RAID Manager

• EXT4, NTFS, FAT32, HFS+, exFAT

NONE

• RAID rebuild in RAID 1/5/10.
• System, fan, and drive failure monitoring with LED and audio alerts.
• System sleep during USB cable disconnection and host device hibernation* or shut down.
*Some hosts may not be supported.
• The unused disk drives automatically become the hot spare ones for the RAID 1 and RAID 5 types.

• 1 x 120mm, 12VDC

• 65W adapter (12VDC), 100-240VAC

• HDD Sleep Mode 4.17 W
• Operating Mode, Typical 18.21 W
*Tested with drives fully populated.

• Operating Temperature0 - 40 °C (32°F - 104°F)
• Storage Temperature-20 - 70°C (-4°F - 158°F)
• Relative Humidity5-95% RH non-condensing, wet bulb: 27?C (80.6?F)

N/A

• TR-004 external RAID enclosure
• AC power adapter x 1
• Power Cord x 1
• USB Type-C to Type-A connector cable x 1
• Drive tray keys x 2
• USB cable clip x 1
• Screws for 2.5-inch drives x 12
• Screws for 3.5-inch drives x 16
• Quick Installation Guide (QIG)
