Barcode Scanner ZEBRA DS2278

DS-2278 2D

1D, 2D

USB, Bluetooth (4.0)

Aiming Pattern : Linear 624nm Amber LED
645nm Super-Red LEDs

640 x 480 pixels

Handheld : Up to 5 in./13 cm. per second for 13 mil UPC
Hands-Free : Up to 30.0 in./76.2 cm. per second for 13 mil UPC

+/- 65°; +/- 65°; 0-360°

32.8° H x 24.8° V Nominal

Code 39
Resolution: 5 mil
Near: .2in./.5cm
Far: 6.0 in/15.2 cm.

Code 128
Resolution: 5 mil
Near: .6in./1.5 cm.
Far: 4.0 in./10.1 cm.

PDF417
Resolution: 6.7 mil
Near: .8 in./2.0 cm
Far: 5.7 in/14.5 cm.

UPC
Resolution: 13 mil (100%)
Near: .5 in./.1.3 cm
Far: 14.5 in./36.8 cm.

Data Matrix
Resolution: 10 mil
Near: .3in./.8 cm.
Far: 6.2 in./15.7 cm.

QR
Resolution: 20 mil
Near: .0 in./.0cm
Far: 11 in./27.9 cm.

25% minimum reflective difference

Minimum Element Resolution
Code 39 - 4.0 mil; Code 128 - 4.0 mil;
Data Matrix - 6.0 mil; QR Code - 6.7 mil

1D
Code 39, Code 128, Code 93, Codabar/NW7,
Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)

2D
PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes

Handheld
Hands-Free

Direct Decode Indicator
good decode LEDs
Rear view LEDs
beeper (adjustable tone and volume)

DS2278 and Cradle : 4.5 to 5.5 VDC

Battery :
Capacity 2,400 mAh Li-Ion Battery
110,000 scans at 60 Scans per Minute or 50,000 scans at 10 Scans per Minute
Operating Time Per Full 84.0 Hours

Operating Temperature
DS2278 Imagers :
32.0° to 122.0° F/0.0° to 50.0° C
Presentation Cradle:
32.0° to 104.0° F/0.0° to 40.0° C

Storage Temperature
-40.0° to 158.0° F/-40.0° to 70.0° C

Humidity
5% to 95% RH, non-condensing

Drop Specification
Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete

Tumble Specification
Designed to withstand 250 tumbles in 1.5 ft./.5 m tumbler

Environmental Sealing
IP52

N/A

CR2278 Presentation Cradle
Micro USB Cable
