ข้อมูลสินค้า4G Router TP-LINK (Omada ER706W-4G_V2) Wireless AX3000 Dual Band
4G Router TP-LINK (Omada ER706W-4G_V2) Wireless AX3000 Dual Band
TP-LINK

4G Router TP-LINK (Omada ER706W-4G_V2) Wireless AX3000 Dual Band

ประกัน 3 ปี
รหัสสินค้า: A0168136
  • Wireless Standards : IEEE 802.11b/g/n/ac/ax
  • Signal Rate
    • 2402 Mbps at 5GH
    • 574 Mbps at 2.4GH
  • Interface
    • 1x Gigabit SFP WAN/LAN Port
    • 1x Gigabit WAN Port
    • 4x Gigabit LAN/WAN Ports
    • 2× Nano SIM Card
  • Antenna Type
    • Wi-Fi: Three 5GHz 5.5dBi & 2.4GHz 4.5dBi dual-band detachable antennas
    • LTE: Two 4.0dBi omnidirectional detachable antennas
  • Centralized Management
  • Omada Mesh Technology
  • Support 4G+ Cat6 up to 300 Mbps* (Not compatible with AT&T's Text & Data plans** in the US).
คำค้นหาเร้าเตอร์ใส่ซิมเร้าเตอร์เร้าเตอร์อินเตอร์เน็ตเราเตอร์ใส่ซิมเราเตอร์Router WiFiเราเตอร์ WifiRouter Wireless
ราคาหน้าร้าน ฿7,590

รายละเอียดสินค้า

ข้อมูลผลิตภัณฑ์

BrandTP-LINK
Model

ER706W-4G V2

Standards

LTE Band of US:
• 4G LTE-FDD: B2/B4/B5/B7/B12/B13/B14/B25/B26/B29/B30/B66/B71
(1950/2100/850/2600/750/750/750/1950/850/700/2350/2150/650 MHz)
• 4G LTE-TDD: B41/B48 (2500/3600 MHz)

Antennas

• Wi-Fi: Three 5GHz 5.5dBi & 2.4GHz 4.5dBi dual-band detachable antennas
• LTE: Two 4.0dBi omnidirectional detachable antennas

Transmit/Receive

N/A

Frequency

• Downlink: 300 Mbps
• Uplink: 50 Mbps

Range

N/A

Wireless Functions

• Seamless Roaming
• Mesh (with EAP that supports Mesh)
• OFDMA
• Beamforming
• MU-MIMO
• Rate Limit: Based on SSID/Client
• Airtime Fairness
• Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise
• Multiple SSIDs: 16 in total (8 per radio)

Processor Specs

N/A

CPU CORE COUNT

N/A

Size of RAM

• Flash : 128 MB NAND
• DRAM : 512 MB DDR4

LEDS

• SYS, WLAN, SFP, LTE Signal, WAN (1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act)

Interface

• 1 Gigabit SFP WAN/LAN Port
• 1 Gigabit WAN Port
• 4 Gigabit LAN/WAN Ports

USB Interface

NONE

Button

• Reset Button

Power Switch

N/A

Data Rate

• 2.4 GHz: 574 Mbps
• 5 GHz: 2402 Mbps (HE160)

Operation Mode

N/A

Management

• Centralized Management

Firewall

N/A

VPN Support

• GRE : Only in Standalone Mode
• SSL VPN : 50 Tunnels
• 100 IPSec VPN Tunnels
• LAN-to-LAN, Client-to-LAN
• Main, Aggressive Negotiation Mode
• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
• IPsec Failover
• IKE v1/v2
• MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
• NAT Traversal (NAT-T)
• Dead Peer Detection (DPD)
• Perfect Forward Secrecy (PFS)
• PPTP VPN Server
• PPTP VPN Client (10)?
• 50 Tunnels
• PPTP with MPPE Encryption
• L2TP VPN Server
• L2TP VPN Client (10)?
• 50 Tunnels
• L2TP over IPSec
• OpenVPN Server
• OpenVPN Client (5)?
• 55 OpenVPN Tunnels
• "Certificate + Account" Mode
• Full Mode
• 20 Tunnels

IPv6 support

• StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode

Features

• Automatic Device Discovery
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration

OS compatibility

N/A

System Requirements

• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11
• MAC OS, NetWare, UNIX or Linux

Power Supply

• 12VDC / 2A Power Adapter

Power Supply (PoE)

NONE

Power Consumption

• EU: 15.4W
• US: 17.3W

Environment

• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
• Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
• Operating Humidity: 10% to 90% non-condensing
• Storage Humidity: 5% to 90% non-condensing

Certification

• CE, FCC, RoHS

Package Contents

• ER706W-4G
• Power Adapter
• Quick Installation Guide
