Access Point UBIQUITI UniFi (U7-PRO-Max) Wireless BE15000 Tri Band WiFi 7

U7-Pro-Max

• 802.11a/b/g/n/ac/ax/be

• 6 GHz : 5.9 dBi
• 5 GHz : 6 dBi
• 2.4 GHz : 4 dBi

N/A

• 6 GHz
• 5 GHz
• 2.4 GHz

• Coverage Area : 160 m² (1,750 ft²)

• 8 Spatial Streams (รวมทุกย่าน)
• ความเร็วรวมสูงสุด 15.088 Gbps (Max Aggregate Data Rate)
• รองรับอุปกรณ์เชื่อมต่อพร้อมกัน 500+ เครื่อง (สูงที่สุดในซีรีส์ U7 Pro)
• พื้นที่ครอบคลุม 160 m2 (1,750 ft2)
• Uplink พอร์ต Ethernet 2.5 GbE (RJ45)

N/A

N/A

N/A

• White/Blue

• 1x 1/2.5 GbE RJ45 port

NONE

N/A

N/A

• 6 GHz: Up to 5800 Mbps
• 5 GHz: Up to 8600 Mbps
• 2.4 GHz: Up to 688 Mbps

• AccessPoint

• UniFi Network

NONE

NONE

N/A

• Wireless Meshing
• Band Steering
• 802.11v BSS Transition Management
• 802.11r Fast Roaming
• 802.11k Radio Resource Management (RRM)
• Advanced Radio Management
• Real-Time Spectral Analysis
• Passpoint (Hotspot 2.0)
• Captive Hotspot Portal
- Custom Branding Landing Page
- Voucher Authentication
- Payment-Based Authentication
- External Portal Server Support
- Password Authentication
- Guest Network Isolation
• Private Pre-Shared Key (PPSK)
• WiFi Speed Limiting
• Client Device Isolation
• WiFi Schedules
• RADIUS over TLS (RadSec)
• Dynamic RADIUS-assigned VLAN

N/A

N/A

• 44-57V DC

• 44-57V DC (PoE+) (Not Included)

• 25W

• Ambient Operating Temperature : -30 to 50° C (-22 to 122° F)
• Ambient Operating Humidity : 5 to 95% noncondensing

• CE, FCC, IC, Anatel
