Barcode Scanner NEWLAND NLS-HR2000-BT
- Support Barcode Type : 1D, 2D
- Interface : Bluetooth
- Scan Rate : 60 fps
- Sensor Resolution : 640 x 480 CMOS
- Trigger Mode : Handheld, Continuous, Auto-Induction
- Equipped with an outstanding CPU, this wireless handheld scanner can effortlessly capture highdensity, high-volume and distorted barcodes printed on paper or displayed on screen.
- Adopting the latest Bluetooth 5.0 technology, the NLSHR2000-BT is able to maintain a reliable wireless connection to transmit data. The communication distances up to 100m.
- The NLS-HR2000-BT, built into an IP52-sealed and drop resistant (1.5m) housing with no moving parts, fortifies itself inside and out
- With 2600mAh battery, it will run a comfortable 16 hours of continuous use
รายละเอียดสินค้า
อ้างอิงจาก : www.newlandaidc.com
ข้อมูลผลิตภัณฑ์
NLS-HR2000-BT
1D, 2D
Cradle : USB Type-A (Support USB-KBW, USB-CDC, HID-POS)
Scanner : Bluetooth 5.0, 100m (direct line of sight in open air)
Illumination : White LED
Aiming : Red LED
640 x 480 CMOS
≥3mil
60 fps
Pitch: ±60°, Roll: 360°, Skew: ±60°
Horizontal 45°, Vertical 34°
EAN-13 : 50mm-260mm (13mil)
QR Code : 30mm-170mm (15mil)
Code 39 : 50mm-115mm (5mil)
PDF 417 : 50mm-120mm (6.67mil)
Data Matrix : 35mm-125mm (10mil)
20%
1D : Code 11, Code 128, Code39, GS1-128(UCC/ENA-128), AIM 128, ISBT 128,Codabar, Code 93, UPC-A, UPC-E, Coupon, GS1 Composite, EAN-13, EAN-8, ISSN, ISBN, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, ITF-6, ITF-14, Standard 2 of 5,China Post 25, MSI-Plessey, Plessey, GS1Databar(RSS).
2D : PDF417, QR Code, Aztec, Data Matrix, Micro PDF417, Micro QR, Hanxin Code.
Synchronous mode
Asynchronous mode
Batch mode
Beep, LED, Vibration
Battery : 2600 mAh lithium-ion battery
Expected Charge Time : 6 hours
Expected Battery Life : 16 hours of continuous operation (scan once per 6 seconds)
Operating Temperature : -10°C to 50°C (14°F to 122°F)
Storage Temperature : -40°C to 70°C (-40°F to 158°F)
Battery Charge Temperature : 0°C to 45°C (32°F to 113°F)
Humidity : 5% ~ 95% (non-condensing)
ESD : ±15 KV (air discharge); ±8 KV (direct discharge)
Drop : Scanner: 1.5m; Cradle: 1.2m
Sealing : IP52
Outstanding Performance
Reliable Wireless Communication
Durable Construction
1 x Barcode Scanner
1 x Cradle (Stand)
1 x Battery
1 x Quick Start
