4G Router MERCUSYS (MB135-4G) Wireless AC1200 Dual Band Gigabit

MB135-4G

• IEEE 802.11b/g/n

• 2× External Detachable 4G LTE Antennas
• 2× External Wi-Fi Antennas

• 2.4 GHz < 20dBm (EIRP)
• 5 GHz < 23dBm (EIRP)

• 5 GHz, 2.4 GHz
• 4G LTE (FDD-LTE): B1 / B3 / B5 / B7 / B8 / B20 / B28 (2100/1800/850/2600/900/800/700 MHz)
• 4G LTE (TDD-LTE): B38 / B40 (2600/2300 MHz)
• 3G (HSPA+/UMTS): B1 / B5 / B8 (2100/850/900 MHz)

N/A

• Smart connect
• WPS
• Wireless Schedule
• Wireless Clients Statistics

• LTE Standard : Cat 4 150/50Mbps DL/UL
• Cellular Mode : 4G Preferred , 4G Only, 3G Only
Cellular APN
• Data Roaming
• Network Search
• Profile Create
• APN Settings
• ISP File Upgrade
• PIN Management

NONE

N/A

N/A

N/A

• 1x Power
• 1x Internet
• 1x LAN
• 3x Signal

• 1x 10/100Mbps LAN/WAN Port
• 3x 10/100Mbps LAN Ports
• 1x Nano SIM Card Slot

NONE

• WPS/Wi-Fi?Reset Button

N/A

• 5 GHz: Up to 867 Mbps
• 2.4 GHz: Up to 300 Mbps

• 3G/4G Router
• Wireless Router

• MERCUSYS APP
• Web GUI

• IPv4 SPI Firewall
• IPv6 Firewall

• OpenVPN
• PPTP
• VPN Connections

• YES

Security
• IPv4 SPI Firewall
• DoS Protection
• Service Filtering
• Access Control
• IP & MAC Binding
• IPv6 Firewall

N/A

N/A

• 12V/1A

NONE

N/A

• Operating Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -40°C~60°C (-40°F~140°F)
• Operating Humidity: 10%~90% Non-Condensing
• Storage Humidity: 5%~90% Non-Condensing

N/A

• AC1200 Wireless Dual Band 4G LTE Router (MB135-4G)
• Power Adapter
• RJ45 Ethernet Cable
• Quick Installation Guide
