Access Point TP-LINK (EAP773) Wireless BE11000 WiFi 7

EAP773

• IEEE 802.11 a/b/g/n/ac/ax/be

• 2.4 GHz: 2× 3.0 dBi
• 5 GHz: 2× 3.0 dBi
• 6 GHz: 2× 3.0 dBi

• < 25 dBm (2.4 GHz)
• < 25 dBm (5 GHz)
• < 23 dBm (6 GHz)

• 2.4 GHz
• 5 GHz
• 6 GHz

• 140m (1500 ft²)^§

• MLO
• 4K-QAM
• MU-MIMO
• HE320
• Mesh
• BBS Coloring
• OFDMA
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS:24(8 on each band)
• Wireless Schedule
• Reboot Schedule
• QoS(WMM)
• Rate Limit
• Static IP/Dynamic IP
• RADIUS Accounting
• MAC Authentication

N/A

N/A

N/A

• YES

• 1× 10G Ethernet Port

NONE

• Reset

N/A

• 574 Mbps (2.4 GHz)
• 4320 Mbps (5 GHz)
• 5760 Mbps (6 GHz)

N/A

• Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller

NONE

NONE

NONE

• Captive Portal Authentication
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

N/A

N/A

• 12V/2.5A DC

• 802.3bt PoE

• 25.94 W (802.3bt, full functionality)
• 22.57 W (12/2.5A, full functionality)
• 23.4 W (802.3at decrease 6GHz Power)
• 10.1 W (802.3af, radio off, only main chip and LAN working)

• Operating Temperature: 0 °°C–40 °C (32 °F–104 °°F)
• Storage Temperature: -40 °°C–70 °C (-40 °F–158 °°F)
• Operating Humidity: 10%–90% non-condensing
• Storage Humidity: 5%–90% non-condensing

• CE, FCC, RoHS, IC

• EAP773
• Installation Guide
• Ceiling/Wall Mounting Kits
Note: Power Adapter is NOT included.
