ข้อมูลสินค้ากล้องวงจรปิด 2.8mm HDTVI HIKVISION DS-2CE76D0T-LMFS
HIKVISION
กล้องวงจรปิด 2.8mm HDTVI HIKVISION DS-2CE76D0T-LMFS
ประกัน 3 ปี
รหัสสินค้า: A0150517
- Image Sensor : 2MP , CMOS
- Max. Resolution : 1920 (H) × 1080 (V)
- Lens Type : 2.8mm
- Video Output : CVI/CVBS/AHD/TVI Switchable
- IR Distance : 30m
- Frame Rate : 1080P@30fps,1080P@25fps
- Day/Night Mode : Auto/Color/BW (Black and White)
- Audio Port : Built-in mic
- Protection : IP67
- Casing Material : Metal
ราคาหน้าร้าน ฿560
รายละเอียดสินค้า
ข้อมูลผลิตภัณฑ์
BrandHIKVISION
Model
DS-2CE76D0T-LMFS
Image Sensor
2 MP CMOS
Lens
2.8 mm fixed focal lens
Lens Mount
M12
Angle of View
2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°
3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°
Adjustment Angle
Pan: 0 to 360°
Tilt: 0 to 75°
Rotation: 0 to 360°
Shutter
PAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s
Min. Illumination
0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
IR
Up to 30 m
Video Resolution
1080P @ 30 fps
Video Compression
N/A
Frame Rate
TVI: 1080P @ 30 fps, 1080P @ 25 fps
AHD: 1080P @ 30 fps, 1080P @ 25 fps
CVI: 1080P @ 30 fps, 1080P @ 25 fps
CVBS: PAL/NTSC
Audio
Auto/Manual
Interface
Switchable TVI/AHD/CVI/CVBS
Functions
N/A
Power
12 VDC
Power Consumption
Max. 3.3 W
Working Environment
-40 °C to 60 °C (-40 °F to 140 °F),humidity: 90% or less (non-condensation)
Ingress Protection
IP67
Material
Metal
Package Contents
N/A
