Printer Barcode ZEBRA ZT231
- Print Method : Thermal Transfer & Direct Thermal
- Resolution : 203 DPI
- Print Speed : 12 นิ้ว/วินาที
- Interface : USB / Serial / LAN
- Memory : Flash 256 MB, SDRAM 256 MB
- ใช้กับริบบอน : 110 x 300 (แกน 1 นิ้ว)
- ใช้กับกระดาษ : ความกว้าง 0.75 - 4.5 นิ้ว
- Construction: metal frame and metal enclosures
- Bi-fold media door with large clear window
- Side-loading supplies path for simplified media and ribbon loading
- Thin film printhead with E3™ Element Energy™ Equalizer for superior print quality
- Three-color LEDs for quick printer status
- 4.3” color resistive touch screen with intuitive menu for quick operation and settings
- ENERGY STAR™ certified
- ZebraDesigner Essentials – easy label design tool free at www.zebra.com/zebradesigner
- Real-Time Clock (RTC)
รายละเอียดสินค้า
อ้างอิงจาก : www.zebra.com
ข้อมูลผลิตภัณฑ์
ZT231
Direct Thermal & Thermal Transfer
N/A
256 MB SDRAM memory
256 MB on-board linear Flash memory
203 dpi / 8 dots per mm
12 ips (203 dpi)
4.09 in. / 104 mm
157" / 3988 mm
Media Width : 0.75 in./19.4 mm to 4.50 in./114 mm
Media Roll Size :
8.0 in./203 mm O.D. on a 3.0 in./76 mm I.D. core
6.0 in./152 mm O.D. on a 1.0 in./25 mm I.D. core
Media Thickness : 0.003 in./0.076 mm to 0.010 in./0.25 mm
Media Types : Continuous, die-cut, notch, black mark
Minimum Label and Liner Length
Tear mode: 0.7 in/18 mm
Cutter mode: 1 in/25 mm
Peel mode: 0.5 in/13 mm
Standard Length : 1,476 ft./450 m
Width : 2 in./51 mm to 4.33 in./110 mm
Core : 1.0 in./25.4 mm
USB / Serial / LAN
Bi-color LEDs for quick printer status
Transmissive and reflective sensors
Z7 bitmapped, 1 smooth-scalable (CG Triumvirate™ Bold Condensed) Pre-loaded Unicode™-compliant scalable fonts for EMEA character sets International character sets supporting the following code page: IBM™ Code Page 850
Supports user-defined fonts and graphics, including custom logos ZPL II drawing commands including boxes and lines 64 MB user available Flash memory storage for downloadable objects; 32 MB user-available SDRAM
Linear Barcodes :
Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN with
2 or 5 digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code
2D Barcodes :
Aztec, Codablock, PDF417, Code 49, Data Matrix, MaxiCode, QR Code, MicroPDF417, TLC 39, RSS-14 (and composite)
N/A
N/A
Operating Temp. :
Thermal transfer : 40ºF to 105ºF/5º to 40ºC
Direct thermal : 32ºF to 105ºF/0º to 40ºC
Storage/Transportation Temperature : -40ºF to 140ºF/-40º to 60ºC
Operating Humidity : 20% to 85% non-condensing
Storage Humidity : 5% to 85% non-condensing
Universal auto-ranging (PFC-compliant)
power supply 100-240 VAC; 50-60 Hz
ENERGY STAR certified
Print DNA Software Solutions
N/A
