Router TENDA (AC10 V5.0) AC1200 Dual Band Gigabit WiFi

AC10V5.0

• IEEE 802.11 ac/n/g/b

• 4x 6dBi external antennas

• CE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
• FCC:
<30 dBm (2.4 GHz)
<30 dBm (5 GHz)

• CE:
2.4G: 2412-2472MHz(CH1-CH13)
5G: 5150-5250MHz(CH36-CH48)
• FCC:
2.4G: 2412-2462MHz(CH1-CH11)
5G: 5150-5250MHz(CH36-CH48)
5725-5850MHz(CH149-CH165)

N/A

• SSID Broadcast: Enable/Disable
• Transmission Power: high, medium, low
• Beamforming
• MU-MIMO

N/A

N/A

N/A

• 1x Sys
• 1x WAN
• 1x LAN
• 1x WiFi/WPS

• 1x 10/100/1000Mbps WAN port
• 3x 10/100/1000Mbps LAN ports

NONE

• 1x WPS/Reset button

• YES

• 5GHz: Up to 867Mbps
• 2.4GHz: Up to 300Mbps

• Wireless Router Mode
• AP Mode
• Universal Repeater mode
• WISP Mode

• Web Management

• Forbid UDP flood attack
• Forbid TCP flood attack
• Forbid flood attack
• Forbid WAN PING from internet

• IPsec pass through
• PPTP pass through
• L2TP pass through

• IPv6 Features Supported

• PPPoE Username/password Clone
• Smart WiFi Schedule
• Smart Power Saving
• Smart LED on/off
• Tenda App
• Dual-band in One
• IPv6 Features Supported
• Broadband management
• MAC address clone
• Backup & Restore configurations
• IPTV
• Guest Network
• Firmware upgrade from local

N/A

N/A

• Input : AC 100-240V~50/60Hz, 0.4A
• Output : DC 12V=1A

NONE

N/A

• Operating Temperature: 0°C ~ 40°C
• Storage Temperature: -40°C ~ 70°C
• Operating Humidity:10% ~ 90% RH non-condensing
• Storage Humidity: 5% ~ 90%RH non-condensing.

• CE/FCC/RoHS

• 1x Wireless Router
• 1x Gigabit Ethernet Cable
• 1x Power Adapter
• 1x Installation Guide
