Switching Hub D-LINK (DES-F1010P-E ) 8 Port POE + 2 Port Uplink (5'')
- Standards and Protocols : IEEE 802.3u, 802.3x,802.3 af/at
- Interface
- 8x 10/100Mbps PoE RJ45 port
- 2x 10/100Mbps uplink RJ45 port
- Switching Type : Unmanaged
- Switching Capacity : 2Gbps
- Casing : Metal
- Package Contents
- DES-F1010P-E
- Power Adapter
- Installation Guide
- 96 W PoE budget
- Support IEEE802.3af/at up to 30W per port to PoE compatible devices
- Support transmission Data/PoE up to 250m cable length
- 6KV Lightning protection
- Smart Features: Extend, VLAN, QoS and PoE
- Plug & Play Installation
รายละเอียดสินค้า
อ้างอิงจาก : www.dlink.com
ข้อมูลผลิตภัณฑ์
DES-F1010P-E
8 x 10/100 BASE-T ports PoE
2 x 10/100 BASE-T Uplink ports
Auto MDI/MDI-X adjustment on all ports
IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x ow control
IEEE 802.3af
IEEE 802.3at
Lighting Protection 6KV
Adopt Store-and-forward
10M port maximum 14800pps
100M port maximum 148800pps
2 Gbps
Power, Link/Activity
IEEE 802.3af
IEEE 802.3at
PoE-Capable 1-8 Ports
Lighting Protection 6KV
Power Budget 96 W (36 W max. per PoE port)
Up to 30 W power output per PoE port
External power adapter 60W
Temperature : Operating: 0 to 40 ˚C (32 to 104 ˚F)
Humidity : Operating: 0% to 95% RH non-condensing
Storage : 0% to 95% RH non-condensing
CE, FCC
