EB-770FI

RGB liquid crystal shutter projection system (3LCD)

1920 x 1080 (FHD)

N/A

N/A

Standard : 77” screen 43.3cm

White Light Output (Normal / Extended) : 4,100lm / 2,800lm
Colour Light Output : 4,100lm

2,500,000 : 1

N/A

Zoom (Wide):
49” to 123” (32.5 – 89.3 cm) @ 4:3
56” to 140” (32.5 – 89.3 cm) @ 16:6
60” to 150” (32.5 – 89.3 cm) @ 16:9
55” to 139” (32.5 – 89.3cm) @ 16:10
57” to 142” (39.4 – 85.3cm) @21:9

Zoom (Wide): (With Interactive function)
59.9” to 100” (32.5 – 57.7 cm) @ 16:9
55.4” to 100” (32.5 – 71.8 cm) @ 16:10
48.9” to 100” (32.5 – 62.8 cm) @ 4:3
55.7” to 110” (32.5 – 69.2 cm) @ 16:6
56.8” to 110” (32.5 – 67.8cm ) @21:9

0.25 - 0.35

Type : No Optical Zoom / Focus (Manual)
F-Number : 1.60
Focal Length : 3.7mm

N/A

1 - 1.35 (Digital Zoom)

N/A

Analog Input:
Computer In: 2
Composite: 1

Digital Input:
HDMI In: 3 (HDCP 2.3)

Analog Output:
Computer Out: 1 (Share with Computer2)

Audio Input:
Audio In: 3 (Stereo Mini)

Audio Output:
Audio Out: 1 (Stereo Mini)

Mic I/O:
Mic In: 1 (Stereo Mini)

Control I/O:
RS232C: 1 (D-sub 9pin)
Interactive Sync: 1 (Stereo Mini)
Finger Touch Unit Control: 1 (Mini DIN 8pin)

USB I/O
Type A: 2 (1 (Side): For PC Free, FW Update, Copy OSD Settings; 1 (Rear): For PC Free, FW Update, Copy OSD Settings or 5V/2A Power Supply)
Type B: 2 (For FW Update, Copy OSD Settings, USB Display)

None

1 x LAN (RJ45)

16W Mono

Laser Diode

Normal / Quiet / Extended : 20,000 / 20,000 / 30,000 hrs

Vertical/Horizontal Keystone:
±3° / ±3°

Quick Corner:
Yes (Auto / Manual)

Fan Noise (Normal / Eco) : 37dB / 27dB

Noise Reduction
Super-Resolution
Detail Enhancement

100 - 240 V AC ±10%, 50/60 Hz

Lamp (Normal / Extended) : 263W / 199W
Standby : (Network On / Off): 2.0W / 0.5W

Operating Temperature:
0 - 2,286 m (0 - 7,500 ft): 0 °C - 40 °C [32 °F - 104 °F ] ; 20% to 80% Humidity, No Condensation
Over 2,286 m (7,500 ft): 0 - 35 °C [32 °F - 95 °F] ; 20%-80% Humidity, No Condensation

Operating Altitude :
Over 1,500 m / 4,921 ft, with High Altitude Mode: 0 - 3,048 m (0 - 10,000 ft)

Power Cable : 1.8m x 1
Remote Control with 2xAA Battery
