กล้องไร้สาย Smart Camera (2.0MP+8.0MP) EZVIZ H80x-R100-8G82WKFL Outdoor

CS-H80x-R100-8G82WKFL

• 2MP + 8MP , 1/2.7” + 1/2.9” Progressive Scan CMOS

• 4mm @ F1.0 (1080p)
• 4mm  @ F1.6 (4K)

• M12

N/A

N/A

• Viewing angle: 46° (Vertical), 87° (Horizontal), 103° (Diagonal) (1080p)
• Viewing angle: 46° (Vertical), 87° (Horizontal), 103° (Diagonal) (4K)

• Pan: 340°, Tilt: 70°

• Self-adaptive shutter

• 0.01 Lux @ (F1.0, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)

• 30m

• ColorFULL Night Vision under Ultra-Low Light

• Digital WDR

• 3840 × 2160

• H.265 / H.264

• Self-Adaptive during network transmission

• Two-Way

• Wi-Fi Standard : IEEE802.11b, 802.11g, 802.11n
• Frequency Range :  2.4 GHz ~ 2.4835 GHz
• Channel Bandwidth :  Supports 20MHz
• Security :  64 / 128 - bit WEP, WPA / WPA2, WPA-PSK / WPA2 - PSK
• Transmission Rate :  11b : 11 Mbps, 11g : 54 Mbps, 11n : 150 Mbps
• Wi-Fi Pairing :  AP paring

• Supports microSD Card (Up to 512 GB)
• Supports EZVIZ CloudPlay storage (Subscription required)

• 1x RJ45 (10M / 100M Adaptive Ethernet Port)

N/A

• AI-powered human shape detection AI-powered vehicle shape detection

NONE

• EZVIZ Cloud Proprietary Protocol

• Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark

N/A

• DC 12V/1A

• MAX. 12W

• Operating Conditions : Conditions30ºC ~ 50ºC Humidity 95% or less (non-condensing)

• IP65

• H80x Dual 4K Camera
• Drill Template
• Waterproof Kit
• Screw Kit
• Power Adapter
• Regulatory Information × 2
• Quick Start Guide
