Access Point TP-LINK (EAP115 WALL) Wireless N300

EAP115-WALL

• IEEE 802.11n/g/b

• 2× Internal 1.8 dBi Omni

• Coverage :  25m (300 ft)

• 2.4 GHz

• ≤20 dBm (2.4 GHz)

N/A

N/A

N/A

• Yes

• 1× 10/100 Mbps Ethernet Port

• LED/Wi-Fi Button
• RESET

N/A

• 11n: Up to 300 Mbps (dynamic)
• 11g: Up to 54 Mbps (dynamic)
• 11b: Up to 11 Mbps (dynamic)

• Captive Portal Authentication
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Local LAN port based VLAN
• Rogue AP Detection
• 802.1X Support
• 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK

• Multiple SSIDs (Up to 8 SSIDs)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• Load Balance
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client

• YES

• PoE (IEEE 802.3af)

• 2.8 W

• Operating Temperature: 0–40°C (32–104°F)
• Storage Temperature: -40–70°C (-40–158°F)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing

• CE, RoHS

• 300 Mbps Wireless N Wall-Plate Access Point EAP115-Wall
• Installation Guide
• Mounting Screw
