เครื่องบันทึก NVR 8CH. VIGI NVR1108H-W

NVR1108H-W

• IP Video Input : 8-Channel
• Incoming Bandwidth : 80 Mbps
• Outgoing Bandwidth : 60 Mbps
• Audio Compression : G.711A/G.711U/G.726

• HDMI Output Resolution :  1 Channel, Resolution: 3840 ×2160/30Hz, 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• VGA Output Resolution :  1 Channel, Resolution: 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• Video Output Mode :  HDMI/VGA Simultaneous Output
• Multi-View Display : 1/4/6/8

• Video Compression :  H.265+/H.265/ H.264+/H.264
• Encoding Resolution : 8 MP/ 5MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
• Synchronous Playback : 8-Channel
• Capability
- 25fps 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP
- 30fps : 4-ch @ 3MP, 2-ch @ 5MP

• Protocol : UPnP (Plug and Play), NTP (Network Timing), SMTP, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
• Mobile Phone Access : Android, iOS
• Web Browser : Chrome (57+), Firefox (52+), Edge (91+)
• Interoperability : ONVIF Profile S, CGI
• Standards and Protocols : IEEE 802.11b/g/n
• WiFi Channels : UN: 1-13 , US: 1-11
• Wireless Name : SSID Configuration , Radio
• Network Switch : Yes
• Frequency  : 2.4 GHz
• Radio Bandwidth
- Auto: Yes
- 20M: Yes
- 40M: Yes
• Wireless Rate : 300Mbps(802.11n), 2 × 2 MIMO
• Wireless Security : WPA-PSK/WPA2-PSK

• ONVIF Profile S, CGI

• 1× RJ-45 10/100 Mbps Self-Adaptive WAN/LAN Ethernet Interface
• 1× RJ-45 10/100 Mbps Self-Adaptive LAN Ethernet Interface
• 2× USB 2.0
• 1x VGA
• 1x HDMI
• 1x SATA Interface

• Up to 10 TB Capacity for Each HDD

• DC 12V/2A

• 5.7 W (Without Disk)
• 16.3 W (Without Disk)

NONE

• Working Humidity : 10%~90% RH Non-Condensing

N/A
